Product >>ECG/EKG cables>>compatible Fukuta ME Cardisuny 10 leads/12 leads EKG cable

fukuda ME ten leads ECG cable

Description: Connector: DB 15pin male connector; Medical TPU jacket; shielded cable; anti-noise design; gold plated pins; more details about cable structure:
Compatibile with : Fukuda ME Cardisuny

Part No OEM No Description Compatibility
EKG-10052A    integrated; IEC, DB15M-Din3.0 KP-309/KP-405/KP-500/
C100 C110 C120 C300 C310 C550 C600 C600W C610 C610W C625 α2000 series; α1000
EKG-10052B    integrated; AHA, DB15M-Din3.0
EKG-10052C   integrated; IEC,DB15M-Banana4.0
EKG-10052D   integrated; AHA,DB15M-Banana4.0
EKG-10052E   integrated; IEC,DB15M-Clip end
EKG-10052F   integrated; AHA,DB15M-Clip end
EKG-10052G   integrated; IEC,DB15M-snap end
EKG-10052H   integrated; AHA,DB15M-snap end
EKG-10053A    integrated; IEC, DB15M-Din3.0  KP-309D/KP-405D/KP-500D/
C100 C110 C120 C300 C310 C550 C600 C600W C610 C610W C625
α2000 series; α1000; (EKG-10009Q---EKG-10009x are with 20k built-in resistor for defibrillation protection)
EKG-10053B    integrated; AHA, DB15M-Din3.0
EKG-10053C   integrated; IEC,DB15M-Banana4.0
EKG-10053D   integrated; AHA,DB15M-Banana4.0
EKG-10053E   integrated; IEC,DB15M-Clip end
EKG-10053F   integrated; AHA,DB15M-Clip end
EKG-10053G   integrated; IEC,DB15M-snap end
EKG-10053H   integrated; AHA,DB15M-snap end

Core technology:

1, All the leads we have longer length to coordinate with bigger size patients without difficulty.

2, the shileidng we have "Super-shield" technology to make it completely grounded and prevent any signal interference even in the complicated OR environment

3, the wires we use bigger size, very durable; surface is convenient for cleaning

4, the banana connector is specifically enhanced to make sure not signal loss even after long time usage.

compliance with
ANSI/AAMI EC53; ICE 60601-1 ISO10993-1 ISO 10993-5 ISO 10993-10

About AHA/IEC color system please read here:

fukuda ME ten leads ECG cable

fukuda ME ten leads ECG cable connector


fukuda ME ten leads ECG cable

multi use adapter to use with disposible electrodes...

ten leads ECG connector banana to adapter to disposible ecg electrodes
