Compatible Bionet SpO2 Extension Cable
Medical Intermediate Adapter Lines for Direct Patient Monitor Interfaces
Engineered for complete connectivity split matching, these trunk cables adapt device-side proprietary connections down to clean DB9 ports, allowing seamless pairing with modular short SpO2 sensors.
New Style Trunk Configuration
- Original Part Reference: B-SPCBL-N / B-SPCBL-NP
- Cable Length: 1.0 Meter (3.3 Feet)
- Monitor Connector Side: Round Rectangular 6-Pin
- Sensor Connection Side: DB9 Female Port
- Equipment Compatibilities: Modern Bionet BM3, BM3 Plus, BM5 Series Systems
Old Style Trunk Configuration
- Original Part Reference: Legacy System Layouts
- Cable Length: 2.4 Meters (7.8 Feet)
- Monitor Connector Side: LEMO 7-Pin Single Notch Plug
- Sensor Connection Side: DB9 Female Port
- Equipment Compatibilities: Early Generation Bionet Monitor Platforms
Technical Reference Media:
Integrated Direct Configuration Reference:
Looking for one-piece direct sensors? We also provide continuous 3-meter integrated sensor configurations matching these interfaces.
Video 1: Compatible Bionet New Style Extension Cable Overview
Video 2: Clinical Monitor Interfacing Demonstration (BM3 / BM5)
Video 3: Legacy Lemo 7-Pin System Conversion Adapter Line Analysis
