Edan SpO₂ Modules Explained: Types, Differences, and Compatibility Guide Edan SpO₂ sensors list chronologically very old legacy: 5pins old model IM3 IM8 IM30 6pins newer models SpO₂ sensor (7 pins, Elite V5 V6) for handheld models H100B （9 pins Nellcor sensor） adapter cables for Edan monitors (6 pins) adapter cables for Edan monitors (7 pins) short length version SpO₂ sensor (7 pins) compatible Edan Nellcor Oximax SpO₂ sensors Part Number / Model Sensor Type Patient Type Technology Family Connector Type Typical Compatible Monitor Families Notes 02.01.210119-11 Finger Clip Adult Standard Edan Digital Lemo PM series, CMS series Reusable 02.01.210120-11 Finger Clip Adult Standard Edan Digital DB9 PM series with extension cable Reusable 02.01.210121-11 Soft-tip / Clip Pediatric Standard Edan Digital DB9 PM series Smaller finger size 02.01.210122-11 Soft-tip Silicone Adult Standard Edan...
Please confirm the exact monitor model, module technology, connector shape, cable configuration, patient size and original part number where available before ordering.
Compatibility and Reference Information
| Part Number / Model | Sensor Type | Patient Type | Technology Family | Connector Type | Typical Compatible Monitor Families | Notes |
|---|---|---|---|---|---|---|
| 02.01.210119-11 | Finger Clip | Adult | Standard Edan Digital | Lemo | PM series, CMS series | Reusable |
| 02.01.210120-11 | Finger Clip | Adult | Standard Edan Digital | DB9 | PM series with extension cable | Reusable |
| 02.01.210121-11 | Soft-tip / Clip | Pediatric | Standard Edan Digital | DB9 | PM series | Smaller finger size |
| 02.01.210122-11 | Soft-tip Silicone | Adult | Standard Edan Digital | DB9 | PM series | Long-term comfort |
| 12.01.110492-11 | Wrap / Y Sensor | Neonatal | Standard Edan Digital | DB9 | Neonatal monitoring systems | Wrap-around type |
| SH1.LEMO | Hard-shell Finger Clip | Adult | Standard Edan Digital | Lemo | PM50 / PM60 / older Edan monitors | Common reusable probe |
| Adult OxiMax Finger | Finger Clip | Adult | Nellcor OxiMax Compatible | 8-pin Lemo | M3/M8/iM series | Higher-end systems |
| Pediatric OxiMax Finger | Finger Clip | Pediatric | Nellcor OxiMax Compatible | 8-pin Lemo | iM series / M series | Smaller sensor geometry |
| Neonatal OxiMax Wrap | Wrap Sensor | Neonatal | Nellcor OxiMax Compatible | 8-pin Lemo | ICU / NICU systems | Sensitive low perfusion |
| Multi-site OxiMax | Multi-site | All Patients | Nellcor OxiMax Compatible | 8-pin Lemo | ICU monitors | Can attach to multiple sites |
| Ear Clip OxiMax | Ear Clip | Adult | Nellcor OxiMax Compatible | 8-pin Lemo | ICU / surgical systems | Better under low perfusion |
| Forehead OxiMax | Forehead Sensor | Adult | Nellcor OxiMax Compatible | 8-pin Lemo | Advanced monitoring systems | Motion-resistant applications |
