EDAN F6 / F6 Express Fetal Monitor LCD Backlight Inverter Board
High-voltage CCFL backlight inverter board for compatible EDAN F6 and F6 Express fetal and maternal/fetal monitors.
Product Overview
This inverter board supplies the high-voltage output required by the CCFL backlight in compatible EDAN F6 and F6 Express displays. It may be used during repairs involving a diagnosed inverter failure, dark display or unstable backlight. This component is the display backlight inverter only. It is not the LCD panel, display-control board or main power-supply board.
Application and Ordering Notes
Confirm the monitor model, LCD backlight type, board markings and connector layout before ordering. Later equipment revisions fitted with LED-backlit displays may not use this inverter board.
The board produces high voltage and should be installed or tested only by qualified service personnel.
Product Gallery
Quality and Compatibility Notice
Compatibility information is provided for reference. Please verify the exact connector, model, and clinical application before ordering.
