Mindray BeneHeart D2 D3 Defibrillator Power Supply Board
Internal power supply board for compatible Mindray BeneHeart D2 and D3 defibrillator-monitors. The assembly includes the transformer, filtering components, fuses, capacitors, inductors, and heatsink shown in the photograph.
Product Overview
This power supply PCB is used in compatible Mindray BeneHeart D2 and D3 defibrillator-monitors as part of the internal power conversion and distribution system. It is to replace an original board affected by power-up failure, unstable output, damaged connectors, heat damage, failed capacitors, or other board-level faults after diagnosis by a qualified technician. The supplied configuration is limited to the board and attached components visible in the photograph. The defibrillator, battery, high-voltage therapy board, main board, cables, and other assemblies are not included unless specifically confirmed.
Application and Ordering Notes
Before ordering, compare the original board’s complete part number, PCB revision, dimensions, mounting holes, connector locations, transformer and heatsink layout, fuse arrangement, and component markings with the photograph. Mindray BeneHeart D2 and D3 hardware revisions may use different power boards. This high-voltage medical-device component should be installed and tested only by qualified service personnel following the manufacturer’s procedures.
Product Gallery
Quality and Compatibility Notice
Compatibility information is provided for reference. Please verify the exact connector, model, and clinical application before ordering.
