Product information
Specifications
| Brand |
Mindray |
| Compatible Model |
N12 N15 N17 |
| Product Type |
Maintenance Part |
| Category |
Machine maintenance parts |
| Note |
Product Information |
| Note |
Specification Details |
| Note |
Brand Mindray |
| Note |
Product Category Patient-monitor display and front housing assembly |
| Note |
Compatible Series BeneVision N Series |
| Note |
Applicable Models BeneVision N12, N15 and N17 |
| Note |
Display Type Medical-grade color TFT LCD with capacitive touchscreen |
| Note |
Available Display Suppliers NLT and Sharp versions |
| Note |
Photograph Shown BeneVision N12 version |
| Note |
Condition Original Mindray part; exact stock condition to be specified |
| Note |
Installation Internal replacement assembly |
| Note |
Package Contents According to the selected assembly and quotation |
Product Overview
This original Mindray replacement assembly is intended for the repair of compatible BeneVision N-Series patient monitors with a damaged display, touchscreen, front bezel or associated front-panel components. Versions are available for the BeneVision N12, N15 and N17. These monitors have different display dimensions, and their front assemblies are not interchangeable. Mindray also used different LCD supplier versions, including NLT and Sharp configurations. The correct assembly must therefore be selected using the monitor model, serial number, existing FRU number, LCD label and connector arrangement. The product photograph shown on this page is the BeneVision N12 version. Photographs of N15 and N17 assemblies can be supplied upon request or added when available. Available Versions and Part Numbers Monitor Model Display Size Display Version Front Housing Assembly FRU BeneVision N12 12.1 inches NLT 115-044502-00 BeneVision N12 12.1 inches Sharp 115-044503-00 BeneVision N15 15.6 inches NLT 115-044544-00 BeneVision N15 15.6 inches Sharp 115-044545-00 BeneVision N17 18.5 inches NLT 115-044551-00 BeneVision N17 18.5 inches Sharp 115-044552-00
Application and Ordering Notes
This assembly may be used when repairing:
Cracked or damaged front glass
Unresponsive or inaccurate touchscreen operation
Failed or damaged LCD
Broken front bezel or mounting points
Damaged alarm-light or light-sensor area
Damaged display or touchscreen cables
Physical damage to the monitor’s front assembly
The actual defective component should be diagnosed before replacing the complete assembly.
Important Compatibility Notice
N12, N15 and N17 front assemblies are different and cannot be treated as one universal part. NLT and Sharp versions may also use different LCD cables, touchscreen cables and assembly numbers.
Quality and Compatibility Notice
Compatibility information is provided for reference. Please verify the exact connector, model, and clinical application before ordering.
