Replacement Battery for Mindray DPM2 / PM-60 Pulse Oximeter – 3.7V 1800mAh Li-ion – LI11S001A
Rechargeable 3.7V 1800mAh Li-ion replacement battery compatible with selected Mindray DPM2 and PM-60 devices. Replaces LI11S001A, M05-010003-08 and M05-010004-08 battery references.
Product Overview
This rechargeable Li-ion battery is designed as a compatible replacement for selected Mindray DPM2 and PM-60 medical devices. It provides a nominal voltage of 3.7V, a rated capacity of 1800mAh and approximately 6.66Wh of nominal energy. The Mindray PM-60 is a compact pulse oximeter intended for spot-check and continuous monitoring of SpO₂ and pulse rate. Mindray confirms that the device can use a lithium-ion battery or AA alkaline batteries, depending on the selected configuration. Specifications Battery chemistry: Li-ion Nominal voltage: 3.7V Rated capacity: 1800mAh Nominal energy: Approximately 6.66Wh Color: Black Dimensions: Approximately 53.91 × 46.19 × 12.67mm Weight: Approximately 50g Rechargeable: Yes Condition: Compatible replacement battery
Application and Ordering Notes
The part numbers M05-010003-08 and M05-010004-08 are very similar but may be associated with different equipment revisions or battery configurations. The PM-60 can also be configured for AA batteries, so not every unit necessarily uses this rechargeable battery pack.
Before ordering, please send PanSW photographs of the original battery label, contacts and equipment model label. Please also compare the voltage, dimensions and contact arrangement carefully.
Product Gallery
Quality and Compatibility Notice
Compatibility information is provided for reference. Please verify the exact connector, model, and clinical application before ordering.
