Nellcor DS-100A spo2 sensor

---

Product >>SPO2 products (8) >>146. Nellcor DS-100A spo2 sensor (Non-Oximax)

Compatibie with the following brands and models:
Artema:Diascope Datascope :Accutorr Plus,Expert,Passport;Dräger:Cicero,Narkomed,Vitalert 1000 GEMS: Corometrics 118,120,129,188,510,556;GEMS:Critikon  9710,9720 Plus,Compact,Dinamap Select ,MPS ,Oxyshuttle,Pro 300/400 (non-OxiMax®);GEMS: Eagle Series,Dash Series,Hellige Eagle 1000,3000,Eagle SMK ,SMU,SMV,SOLAR Series,TRAM Modular x50SL Series;Invivo Research :M12 (Nellcor® SpO2),Millennia 4500 Plus 2;Invivo/M.D.E .:Escort 100 OPT11A,Escort 300A,Escort II OPT30,Prism (Nellcor® SpO2);Ivy Biomedical :405A,405D,405P,405T,Vital-Guard 450CN ;Mennen:Horizon XL (Nellcor® SpO2) ,MR 1300 Mercury 1200;Nellcor®:N100 (req. preamp cable),N180,N200 (req. extension cable),N-20,NPB-40,NPB-75,NPB-290/5 ,N-390,N-395,N-3000,N-6000;Nihon Kohden: BSM-1102 LifeScope EC,BSM-2304 iPro (LifeScope i),BSM-4102 Procyon LT (LifeScope P),BSM-4104 Procyon (LifeScope P),BSM-4112 Procyon LT (LifeScope P),BSM-4114 Procyon (LifeScope P),BSM-9510 LifeScope M (Nellcor® SpO2),OGS-2000 PocketCare (Nellcor® SpO2); Pace Tech:Vitalmax 800 Series (black face,Nellcor® SpO2);  MEK (nellcor module): MP1000 Siemens :SC6000,SC7000,SC8000,SC9000XL,Sirecust 630 ,Sirecust700,Sirem SpO2 Module; Spacelabs :90351-0/6,90465 (Nellcor®SpO2),90466 (Nellcor® SpO2) ,90467 (Nellcor® SpO2),90489 (Nellcor®SpO2) ,90496/90369/90367 Ultraview (Nellcor® SpO2) ,90651A-08,IM77; Welch Allyn Protocol :Atlas (Nellcor® SpO2),Propaq CS  (Nellcor® SpO2),:Propaq 106-EL,Propaq 202-EL,Propaq 204-EL,Propaq 206-EL,Micropaq (Nellcor® SpO2) ,Spot Vital Signs, Vital Signs (non-OxiMax®)

And any other nellcor module equipped machine without Oximax technology.

connector view

Also the following sensors types available:

Nellcor	DS-100A	RSP-10041A	Nellcor adult finger clip spo2 sensor,3ft
		RSP-10041B	Nellcor adult soft tip spo2 sensor,3ft
		RSP-10041C	Nellcor pediatric finger clip spo2 sensor,3ft
		RSP-10041D	Nellcor pediatric soft tip spo2 sensor,3ft
		RSP-10041E	Nellcor neonate wrap spo2 sensor,3ft
		RSP-10041F	Nellcor adult ear clip Spo2 sensor,3ft
		RSP-10041G	Nellcor animal tongue Spo2 sensor,3ft

For DS-100A Oximax, please refer to: DS-100A Oximax

front view
Reference pins diagram value for engineers:
a, there is a 7.5k ohm resistor between pin 1 & pin 6;
b, pin 3-->LED anode; pin 2-->LED cathode;
c, pin 5-->photodector anode; pin 9-->photodetector cathode;
d, pin 6 for outer shielding; pin 7 for inner shielding;
e; LED & IR frequency: 660/905nm;

adult clip

adult ear clip

adult silicone soft

neonate wrap

pediatric clip

pediatric soft

---

Nellcor D25 disposible spo2 probe	Nellcor DOC-10 series spo2 sensor	Nellcor Oximax spo2 sensor

---
