Compatible rechargeable Li-ion battery with connector plug for the Biocare PM900 patient monitor. This 4S2P18650 battery provides 14.8V, 5200mAh and approximately 76.96Wh of nominal energy.
Send your equipment model, required quantity and destination country. We will help confirm compatibility and availability.
WhatsApp: +86 136 8886 0726
sales@panswmed.com
| Brand | Biocare |
|---|---|
| Compatible Model | Biocare PM900 |
| Product Type | Battery Pack |
| Category | Medical batteries |
| Note | Specification Details |
| Note | Product type Compatible rechargeable patient-monitor battery |
| Note | Battery chemistry Li-ion |
| Note | Nominal voltage 14.8V |
| Note | Nominal capacity 5200mAh / 5.2Ah |
| Note | Nominal energy 76.96Wh |
| Note | Cell format 18650 |
| Note | Cell arrangement 4S2P |
| Note | Typical cell quantity Eight cells |
| Note | Connector Plug included |
| Note | Primary battery description 4S2P18650 |
| Note | Compatible equipment Biocare PM900 |
| Note | Equipment type Patient monitor |
| Note | Condition New compatible replacement battery |
This compatible Li-ion battery is designed to provide portable and backup power for the Biocare PM900 patient monitor. The battery uses a 4S2P cell configuration, normally consisting of eight 18650 cells arranged as four series-connected groups with two parallel cells in each group. This configuration provides a nominal voltage of 14.8V and a rated capacity of 5200mAh. The battery is rechargeable and supplied with a connector plug. However, 4S2P18650 is a general construction description used for many battery packs. The plug, polarity, protection board, communication contacts and dimensions must match the original Biocare battery.
This battery is intended to support portable and backup operation of the compatible Biocare PM900 patient monitor.
Typical applications include:
Bedside patient monitoring
Emergency-department monitoring
Intensive-care monitoring
Operating-room monitoring
Clinical rounds
Patient transport
Temporary operation away from AC power
Backup operation during short power interruptions
Actual runtime depends on the monitor configuration, installed modules, display settings, alarm activity, battery condition and operating environment.
Compatibility information is provided for reference. Please verify the exact connector, model, and clinical application before ordering.
