CCFL display backlight inverter/driver board 2023703-001 for compatible GE Dash 1800 and Dash 2500 patient monitors. The PCB is marked 20223173-001 Revision A.
Send your equipment model, required quantity and destination country. We will help confirm compatibility and availability.
WhatsApp: +86 136 8886 0726
sales@panswmed.com
| Brand | GE |
|---|---|
| Compatible Model | Dash 1800 Dash 2500 |
| Product Type | Maintenance Part |
| Category | Machine maintenance parts |
| Product type | CCFL display backlight inverter/driver board |
| Compatible brand | GE |
| Compatible models | Dash 1800 and Dash 2500 |
| Assembly part number | 2023703-001 |
| Assembly revision | Revision A |
| PCB number | 20223173-001 |
| PCB revision | Revision A |
| PCB description | GEHC-CS CCFL Driver Board |
| Inverter module | TDK-Lambda CXA-P10A-P |
| Condition | Confirm before ordering |
| Included item | One specifically quoted inverter board |
| LCD display included | No |
| Complete patient monitor included | No |
Replacement CCFL backlight inverter and driver board for compatible GE Dash 1800 and Dash 2500 patient monitors. The photographed board carries the assembly marking 2023703-001, Revision A and PCB marking PWB 20223173-001, Revision A. It is identified on the PCB as a GEHC-CS CCFL Driver Board. The installed high-voltage inverter module is marked TDK-Lambda CXA-P10A-P. This board supplies the high-voltage output required by the monitor’s CCFL display backlight. Different LCD panels, backlight technologies, PCB revisions and connector configurations may exist. Please compare all board markings and connectors before ordering. Installation should be performed by qualified service personnel because the board produces high voltage. This listing includes only the specifically quoted inverter board. The LCD screen, backlight lamps, cables and complete patient monitor are not included.
Different LCD panels, CCFL backlights, PCB revisions and connector arrangements may exist. Before ordering, please send PanSW the monitor model, serial number, original board number and clear photographs of the board, connectors and installed LCD panel label.
Compatibility information is provided for reference. Please verify the exact connector, model, and clinical application before ordering.
Send the model, part number and a clear photo.
